CHAPTER 6 PG-FP4 OPERATION IN STANDALONE MODE
[ Program > ]
When the Enter button is pressed next, the target device connected to the PG-FP4 is
.
programmed
Notes 1, 3
↓ Next button
[ Erase > ]
When the Enter button is pressed next, the target device connected to the PG-FP4 is
erased
↓ Next button
Note 3
.
[ Verify > ]
When the Enter button is pressed next, the target device connected to the PG-FP4 is
verified
↓ Next button
Notes 1, 3
.
[ Security > ]
When the Enter button is pressed next, the security flag of the target device connected to the
↓ Next button
PG-FP4 is programmed
Note 2
.
[ Checksum > ]
When the Enter button is pressed next, the checksum value (entire flash memory area of the
target device) of the target device connected to the PG-FP4 is read. The read checksum
value will be displayed on the message display Notes 2, 3 .
↓ Next button
[ Blank check > ]
When the Enter button is pressed next, blank check of the target device connected to the
PG-FP4 is executed Note 3 .
↓ Next button
[ Signature > ]
When the Enter button is pressed next, the signature of the target device connected to the
PG-FP4 is read. The device name is displayed on the message display.
Display example
Signature:
D70F3025A
↓ Next button
[ Prog Area > ]
When the Enter button is pressed next, the valid memory area (Area 0 or Area 1) is changed
if the 2 MB user program area is used as two independent 1 MB memory areas (Area 0 and
Area 1).
? Display example (when Enter button is pressed)
Commands
Prog Area now: 0 (The valid memory area is changed from Area 1 to Area 0 .)
If the 2 MB area is used as one user program area, the valid memory area cannot be
changed by using this menu.
? Display example (when Enter button is pressed)
Commands
Prog Area (dis.) (The valid memory area cannot be changed.)
Check the memory area currently selected, by using Prog Area of Option Setting.
Notes 1. Download the user program in advance in the GUI software mode.
2. This command is valid only with a single-power-supply flash memory microcontroller. If any other
microcontroller is used, this command is not displayed.
3. This is valid for the programming area (Chip, Block and Area) currently set for the PG-FP4.
User ’s Manual U15260EJ4V0UM
81
